Blast Chiller 5 Trays
Cooling & Freezing Performance
Blast Chilling
8 kg from +70°C to +3°C
90 minutes
Shock Freezing
5 kg from +70°C to -18°C
240 minutes
Key Features
🌡️ Core Temperature Probe
Ensures precise cooling at the heart of your product for optimal food safety and quality.
💻 4 Electronic Programs
Fully programmable electronic thermostat for blast chilling or shock freezing operations.
🏗️ Premium Construction
AISI 304 stainless steel body with 70mm insulation thickness for superior thermal efficiency.
🔧 Anti-Corrosion Evaporator
Treated evaporator built to last in high-humidity professional kitchen environments.
⚙️ Premium Compressor
Danfoss or Aspera compressor with EBMFAN components ensures long-term reliability.
🚪 Replaceable Door Heater
Door mullion heater prevents ice buildup and maintains perfect sealing.
🌍 Climate Class 5
Operates effectively in ambient temperatures up to 40°C – perfect for hot climates.
🔇 Quiet Operation
Only 60 dB noise level ensures a comfortable working environment.
♻️ Eco-Friendly
R290 refrigerant – environmentally responsible cooling solution.
❄️ Dual Defrost System
Automatic and manual defrost modes with hot gas defrosting technology.
🧼 Hygienic Design
Rust-resistant stainless steel construction is easy to clean and maintain.
📦 Flexible Tray Options
Accommodates 5 × GN1/1 trays or 400×600 mm pans (trays not included).
Technical Specifications
| Feature | Specification |
|---|---|
| External Dimensions | 800 × 877 × 840 mm |
| Body Thickness | 0.8 mm (AISI 304 Stainless Steel) |
| Insulation Thickness | 70 mm |
| Refrigerant | R290 (eco-friendly) |
| Electrical Supply | 220V / 50Hz |
| Power Consumption | 720 W |
| Weight (Net/Gross) | 105 / 138 kg |
| Installation | 4 adjustable feet |
| Tray Capacity | 5 × GN1/1 or 400×600 mm |
| Noise Level | 60 dB |
| Climate Class | Class 5 (up to 40°C ambient) |
