Combi Oven Unox 5

Combi Ovens

( XECC-0523-E1RM)

Electric Combi OvenCHEFTOP MIND.MapsTM ONE COMPACT

Combi Oven Unox 5 Description :

Technologically advanced combi oven for gastronomy cooking processes
(dehydrating, steaming, low temperature cooking, sous vide cooking, roasting,
grilling, pan frying, regeneration and plate regeneration) and for fresh or frozen
baking thanks to the Unox Intensive Cooking and Intelligence Performance
technologies which guarantee perfect results and repeatability for any load size.
Automatic management of cooking processes (CHEFUNOX) for perfect results
even without trained staff.

STANDARD COOKING FEATURES

Manual cooking
● Temperature: 30 °C – 260 °C
* Up to 9 cooking steps
● CLIMA.Control: humidity or dry air set by 10%
* Delta T cooking with core probe
Programs
● 1000+ programs
● MIND.Maps™: draw the cooking processes directly on the display.

ADVANCED AND AUTOMATIC COOKING FEATURES for Unox Intensive Cooking
* DRY.Maxi™: rapidly extracts the humidity from the cooking chamber
● STEAM.Maxi™: produces saturated steam
* AIR.Maxi™: manage fans auto-reverse and pulse function
● CLIMALUX™: total control of the humidity in the cooking chamber

DIMENSIONS AND WEIGHT
Width 535 mm
Depth 672 mm
Height 649 mm
Net Weight 55 kg
Pan spacing 67 mm

POWER SUPPLY

STANDARD will be as following :
Voltage 380-415 V
Phase 3PH+N+PE
Frequency 50-60 Hz
Total power 5,15 kW
Maximum Amp Draw 13 A
Required breaker size* 20 A
Power cable requirement H07RN-F 5G 2.5 mm²
Cord diameter 13,96 mm
Plug NOT INCLUDED

cap: 5 trays GN 2/3 ONE COMPACT. Distance between trays: 67 mm. power :230V-400V/ 5.2 kw.

weight : 56 kg. external dimensions : 535 x 672 x 649 mmXECC-0523-E1RM/UNOX/italy made
