Fiorenzato F5D Coffee Grinder
The Fiorenzato F5D coffee grinder is a professional grinder-doser for cafés, coffee shops, restaurants, hotels, bakeries, and beverage service counters. It combines 64 mm flat burrs with a traditional ground-coffee doser for consistent espresso preparation.
In addition, the continuous micrometric adjustment helps baristas refine the grind setting for different coffee blends. The large bean hopper and adjustable dose mechanism also support regular commercial service.
Key Specs Summary
| Buying Point | Details |
|---|---|
| 64 mm Flat Burrs | Designed for consistent professional espresso grinding |
| Traditional Doser | Stores and dispenses measured portions of ground coffee |
| 350 W Motor | Suitable for regular café and restaurant service |
| Continuous Adjustment | Micrometric ring adjustment supports precise grind control |
| 1.5 kg Hopper | Provides useful bean capacity for commercial operation |
| Adjustable Dose | Dose setting from 5.5 to 10 grams |
Call WhatsApp Request Quotation
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Fiorenzato |
| Model | F5D |
| Product Type | Professional coffee grinder with doser |
| Supplier | Available through ALPHA |
| ALPHA Supply Reference | ALPHA project-ready specification for professional coffee grinder supply |
| Power | 350 W |
| Burr Type | Flat burrs |
| Burr Diameter | 64 mm |
| Burr Speed | 1350 rpm at 50 Hz and 1550 rpm at 60 Hz |
| Grinding Adjustment | Continuous micrometric adjustment through the ring nut |
| Dose Adjustment | 5.5 to 10 g per dose |
| Bean Hopper Capacity | 1.5 kg |
| Doser Capacity | 250 g |
| Fork | Standard portafilter fork |
| Body | Painted die-cast metal |
| Dimensions | 230 x 615 x 270 mm |
| Net Weight | 14 kg |
| Available Controls | Automatic doser filling, timer, or manual switch depending on supplied version |
Best For
- Coffee shops and espresso bars.
- Restaurants and hotel beverage counters.
- Bakeries and cafés.
- Office and institutional coffee stations.
- Businesses that prefer a traditional grinder-doser workflow.
Traditional Grinder-Doser Operation
The Fiorenzato F5D grinds coffee into a 250 g doser chamber. The barista can then dispense measured portions directly into the portafilter. This workflow works well in service areas that prepare espresso continuously during busy periods.
Moreover, the adjustable dose mechanism allows portions from 5.5 to 10 grams. This range helps operators match the dose to the coffee recipe and portafilter size.
Continuous Micrometric Grind Adjustment
The adjustment ring provides continuous micrometric control instead of fixed steps. As a result, the barista can make small changes to the grind size when coffee age, humidity, extraction time, or espresso recipe changes.
For reliable results, adjust the grinder gradually and test the extraction after each change. The final grind setting depends on the coffee beans, espresso machine, basket, dose, and target beverage.
Available F5 Control Versions
| Version | Control Method |
|---|---|
| F5 A | Microswitch for automatic doser filling |
| F5 T | Timer-controlled operation |
| F5 M | Manual switch operation |
Installation and Usage Notes
- Confirm the supplied voltage, frequency, plug type, and control version before ordering.
- Place the grinder on a stable counter beside the espresso machine.
- Allow enough overhead clearance for filling and removing the bean hopper.
- Keep the grinder away from water, steam, and excessive heat.
- Adjust the grind gradually while the motor is operating when required by the manufacturer instructions.
- Do not place fingers or tools inside the hopper or grinding chamber.
- Use freshly roasted coffee beans suitable for espresso preparation.
Cleaning and Maintenance
- Empty and clean the bean hopper regularly.
- Brush coffee residue from the doser chamber and dispensing mechanism.
- Clean the grinder body with a soft, slightly damp cloth.
- Do not wash the grinder body with running water.
- Inspect the burrs periodically and replace them when grinding performance declines.
- Use trained technicians for electrical, motor, or internal grinding-system service.
Delivery and Support in UAE
ALPHA supplies professional coffee grinders, espresso machines, blenders, juicers, and beverage equipment for cafés, restaurants, hotels, bakeries, and foodservice projects across the UAE. Product availability, colour, electrical configuration, and delivery timing can be confirmed before quotation.
For the Fiorenzato F5D coffee grinder, request a quotation from ALPHA.
Warranty and After-Sales Note
Warranty and after-sales support depend on the confirmed quotation and final supplied configuration. Coverage does not include damage caused by foreign objects, unsuitable electrical supply, poor cleaning, incorrect adjustment, misuse, water exposure, worn burrs, or unauthorized repair.
Related Commercial Beverage Equipment
- Commercial Espresso Machine
- On-Demand Coffee Grinder
- Santos Blender 62
- Santos Juicer 50
- Commercial Blender FR150P
FAQ
What type of grinder is the Fiorenzato F5D?
It is a professional espresso coffee grinder with a traditional ground-coffee doser.
What burr size does the F5D use?
The grinder uses 64 mm flat burrs.
What is the bean hopper capacity?
The standard hopper holds up to 1.5 kg of coffee beans.
How much coffee can the doser hold?
The ground-coffee doser has a listed capacity of 250 grams.
Can the dose quantity be adjusted?
Yes. The dispenser can be adjusted from 5.5 to 10 grams per dose.
Is the grinder suitable for a busy café?
It is suitable for regular professional espresso service. However, the required capacity should be reviewed against daily coffee volume and peak service demand.
