Klimaitalia CXF3100TN Refrigerated Counter 3 Doors
The Klimaitalia CXF3100TN refrigerated counter is a 3-door undercounter chiller for commercial kitchens that need chilled storage below the working surface. It helps restaurants, cafés, hotels, cloud kitchens, and catering kitchens keep ingredients close to the preparation line.
This model is available through ALPHA for UAE foodservice projects. In addition, its stainless steel counter design gives staff chilled storage and a practical worktop in one space-saving unit.
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Klimaitalia CXF3100TN Refrigerated Counter 3 Doors |
| Product Type | Commercial 3-door refrigerated counter chiller |
| Brand | Klimaitalia |
| Model | CXF3100TN |
| Supplier | Available through ALPHA |
| ALPHA Supply Reference | ALPHA project-ready specification for commercial refrigerated counter supply |
| External Dimensions | 1795 mm width x 700 mm depth x 850–860 mm height |
| Net Capacity | 291 litres |
| Temperature Range | +2°C to +8°C |
| Cooling Type | Ventilated cooling |
| Door Quantity | 3 solid doors |
| Body Material | Stainless steel commercial body |
| Countertop Use | Stainless steel worktop for preparation and service support |
| Refrigerant | R290a |
| Power and Voltage | 2.25 kWh/24h (Eco-Friendly) |
| Main Application | Chilled ingredient storage below the preparation counter in professional kitchens |
Call WhatsApp Request Quotation
Key Specs Summary
| Buying Point | Details |
|---|---|
| Chilled Storage | 291 litres capacity for ingredients and daily kitchen stock |
| Door Layout | Three-door access supports organized storage by product type |
| Temperature Range | +2°C to +8°C for chilled food preparation storage |
| Counter Function | Top surface supports preparation, plating, and tray handling |
| Professional Use | Suitable for restaurants, cafés, hotels, cloud kitchens, and catering kitchens |
Best For
- Restaurant kitchens that need chilled storage below the preparation counter.
- Cloud kitchens with limited back-of-house space.
- Hotels and catering kitchens storing chilled ingredients near the work line.
- Cafés and bakeries that need chilled preparation storage.
- Food preparation areas that need a refrigerated counter instead of upright refrigeration.
Refrigerated Counter for Kitchen Preparation Lines
The CXF3100TN helps staff keep chilled ingredients directly below the work surface. Therefore, it reduces movement between the preparation counter and separate upright chillers during busy service.
Three-Door Chilled Storage
The three-door layout helps staff organize chilled stock by section. For example, the kitchen can separate sauces, dairy, vegetables, prepared items, or service ingredients according to workflow.
Worktop and Storage in One Unit
The stainless steel top can support preparation, plating, packing, or temporary tray placement. As a result, the unit saves space while giving staff both storage and working surface in one footprint.
Ventilated Cooling System
The ventilated cooling system helps distribute cold air inside the cabinet. In addition, the +2°C to +8°C range supports chilled storage for common preparation ingredients.
Commercial Stainless Steel Body
The stainless steel body suits daily professional kitchen use. Moreover, it supports routine cleaning around preparation zones where hygiene and durability matter.
Correct Model Selection
Before ordering, confirm the final dimensions, voltage, refrigerant, shelf layout, delivery access, and warranty terms. This step helps ensure the supplied refrigerated counter matches the kitchen layout and storage requirement.
Related Refrigerated Counter Options
| Model | Best Use | View Product |
|---|---|---|
| CXF3100BT 3-Door Freezer Counter | Frozen storage below a preparation counter | View Undercounter Freezer 3 Door CXF3100BT |
| PXF2100TN 2-Door Chiller | Chilled pastry or preparation storage | View Chiller 2 Doors PXF2100TN |
| CXF3100TN 3-Door Refrigerated Counter | Chilled storage below a preparation worktop | Current model |
| 2-Door Refrigerated Counter | Compact chilled counter storage | View 2-Door Refrigerated Counter |
| 2-Door Counter Top Freezer | Compact frozen counter storage | View Freezer Counter Top 2 Doors |
| PXF3100TN Pastry Refrigerated Table | Larger pastry and bakery chilled preparation storage | View Pastry Refrigerated Table PXF3100TN |
Installation and Usage Notes
- Confirm the final external dimensions before checking the installation space.
- Keep ventilation clearance around the refrigeration system according to the supplied manual.
- Place the unit away from ovens, fryers, grills, and direct heat where possible.
- Confirm voltage, plug type, temperature range, refrigerant, and warranty terms before quotation approval.
- Allow the chiller to reach the correct temperature before loading products.
- Do not block internal airflow or overload the cabinet.
- Clean door gaskets, handles, shelves, and stainless steel surfaces regularly.
Delivery and Support in UAE
ALPHA supplies refrigerated counters and commercial chillers for restaurants, hotels, cafés, bakeries, cloud kitchens, catering kitchens, and foodservice projects across the UAE. In addition, ALPHA can confirm product availability, delivery timing, final specification, and warranty terms before quotation.
For refrigerated counter selection or project supply, request a quotation from ALPHA with your required storage type and kitchen layout.
GCC Export Support
ALPHA can support selected export orders from the UAE to Qatar and Saudi Arabia. However, availability, packing, delivery terms, shipping cost, and warranty arrangements depend on the selected model, quantity, and destination.
Warranty and After-Sales Note
ALPHA provides after-sales support in the UAE according to the confirmed quotation and supplied refrigerated counter specification. However, warranty coverage does not include damage caused by incorrect electrical supply, poor ventilation, blocked condenser, overloading, misuse, poor cleaning, impact, poor site handling, or unauthorized repair.
Related Commercial Refrigeration Equipment
- Undercounter Freezer 3 Door CXF3100BT
- Chiller 2 Doors PXF2100TN
- 2-Door Refrigerated Counter
- Freezer Counter Top 2 Doors
- Pastry Refrigerated Table PXF3100TN
FAQ
What is the CXF3100TN refrigerated counter used for?
The CXF3100TN stores chilled ingredients below a preparation counter in restaurants, cafés, hotels, catering kitchens, cloud kitchens, and food preparation areas.
How many doors does this refrigerated counter have?
This model has three solid doors for organized access to chilled storage sections.
What is the temperature range?
The listed temperature range is +2°C to +8°C, which suits chilled preparation storage.
What is the net capacity?
The net capacity is 291 litres.
Is this model a chiller or freezer?
The CXF3100TN is a refrigerated chiller counter. For frozen storage, review the CXF3100BT freezer counter.
Can staff use the top as a work surface?
Yes. The counter-style top can support preparation, plating, packing, or temporary tray placement according to the kitchen workflow.
What should be confirmed before ordering?
Confirm dimensions, voltage, refrigerant, shelf layout, availability, warranty terms, and delivery access before quotation approval.
Can ALPHA supply this refrigerated counter across the UAE?
Yes. ALPHA supplies commercial refrigeration equipment across the UAE, subject to availability, delivery requirements, and confirmed quotation terms.
